Solar energy is a widely used clean energy, usually through the solar panels will be converted into electricity for human use, but the direct conversion of electricity is DC, and cannot be directly for electrical appliances to use, then you need to through the inverter will be converted from DC to AC. You may still have some questions about solar panels and inverters, next, I will answer them for you.

How to connect solar panel and 48v inverter

1. Preparation before connection. Prepare the tools needed for the connection before connecting. Choose a suitable location to place the solar panel and inverter to prevent accidents, and make sure you get permission from the government before you start.

2. Choose the series or parallel connection of the solar panels, according to the total power consumption of all the electrical appliances in your home, you can choose series, parallel or a combination of series and parallel connection. You can choose series, parallel or a combination of series and parallel. Just make sure that the final output power can meet the household electricity consumption. Series connection is to connect the positive pole of one solar panel to the negative pole of another solar panel, and so on. Parallel connection is to connect the positive poles of two solar panels.

3. Find the positive and negative terminals of the solar panels and the inverter, use the red cable and connector to connect the positive terminal of the panel and the inverter, and then use the black cable and connector to connect the negative terminal of the panel and the inverter. Finally, use items such as cable ties and clips to secure the cables and connectors.

4. Perform an inspection. After completing the connection, turn on the system to check if the inverter panel is displaying properly and if the inverter is working properly.

5. Protect the solar panels and inverter and do not leave them in a wet place.

6. Maintain your solar system regularly, after installing your solar system, don’t think you can rest on your laurels, regular checkups and repairs are necessary. Otherwise the life span of your solar system will be greatly reduced.

Summarize

The connection between solar panels and 48v inverter is roughly as shown above, if you still haven’t learned how to connect it, it’s better to request the help of a professional electrician. I hope my article can help you.
