50 kWh 48v Lithium Ion Battery Pack
The 50 kwh lithium battery pack is specially designed for home energy storage systems. It comprises 5 units of 48V 200Ah batteries, adjustable in quantity for various pack capacities. With a lifespan exceeding 10 years, it can be charged using solar panel, wind turbine, generator, or grid power. With its outstanding performance and high cost-effectiveness, it has become one of the most popular products in home energy storage.
Also if you have a new energy electric car at home, use the electricity generated by the PV panels during the day to store it in the battery and charge the electric car at night when the car returns home. If you don’t have PV panels installed, then setting up charging times to charge the battery during the day or at night when electricity is cheap can also save you charging costs.
Battery Pack Features:
- Stacked design: Easy to install and adjust. 10kwh, 20kwh, 30kwh, 80kwh, 100kwh, 200kWh etc are available.
- Maintenance free: Place it in a room temperature environment to avoid damage to the casing. Normally it does not require maintenance.
- Buit-in BMS (Battery Management System): Protect the circuit, avoid overcharge, over discharge, high temperature, etc., and allocate the capacity of each battery.
- Hard Case: The 50kWh battery case is made of high-strength metal casing with simple and elegant white color, which makes it a sturdy, practical and exquisite device for your home.
- High weight energy density: with the same battery energy, the weight of lithium batteries is 1/3 of lead-acid batteries. Saves more volume and transportation costs.
- Durable: The failure rate of this battery is 0.8% within 10 years, the quality is extremely stable. When setting the maximum discharge depth of the battery, it is recommended not to discharge 100% of the battery, and at least 10% of the battery power should be retained in the battery each time it is discharged. This will greatly extend the service life of the battery.
- Cheap Battery Price: The price offered by our battery manufacturer only includes the cost of battery materials and labor for production and testing. It is much cheaper than you buy from local wholesalers or dealers.
- High efficiency: The efficiency of the battery is 95% as well as extremely low self-discharge rate for more than 5 years, so that you can get more power when using the battery and avoid power waste.
- Customs design: OEM and ODM service, battery voltage, battery size, charging and discharging current, battery color, etc, most of battery information can be customized design.
- A Grade deep cycle battery cell: EVE battery cell, one of Top 3 brand in China.
- Over 10 years lifespan: The design lifespan is about 15 years.
50 kWh Lithium Battery Application
Specifications of 50 kwh Lithium Ion Battery
The main applications of 50kWh lithium batteries are home energy storage system, factory equipment backup power, off-grid energy storage, commercial energy storage, community energy storage, photovoltaic farms, etc.
| Nominal Voltage: | 48V （16S 51.2V ) |
| Nominal capacity: | 1000Ah |
| battery type: | 16S1P Lifepo4 3.2v 1000AH |
| weight: | ≤500Kg |
| Dimensions: (LxWxH) | Dimensions of the battery case：955*460*1000mm |
| Charging end voltage: | 58.4V16S |
| Connector | M8 bolt screw |
| LED display | LCD display (voltage, capacity, watts, etc.) |
| Low Voltage Protection: | 40V(pack)/2.5V(cell) |
| charging mode: | 0.2C(0.5A) Constant current/constant voltage |
| Communication protocol: | RS485/RS232/CAN |
| Maximum Continuous Discharge Current: | 500A |
| Discharge Over Current Protection: | 500A |
| Over Voltage Protection: | ＞57.6V |
| Operating temperature: | Charge：0~45℃ |
| discharge：-10~55℃ | |
| Storage temperature (60-80% SOC storage): | -10~45℃ |
| Cycle life: | More than 6000 times – 8000 times |
| BMS Protection: | Overcharge, overdischarge, overcurrent, short circuit |
FAQ:
What is lfp battery life?
How many batteries to run a refrigertor?
The calculation formula for the power of a refrigerator is: power (kW)=cooling capacity (W)/efficiency. Among them, refrigeration capacity refers to the amount of refrigeration that a refrigerator can produce within a certain period of time. If the refrigeration capacity of the refrigerator is 10000 W and the efficiency is 0.8, then its power is: 10000/0.8=12500 kW.
