5KVA Hybrid Solar Inverter Product Details
The 5kw hybrid solar inverter is designed to meet the growing number of home PV systems. Its conversion efficiency can reach up to 99% and charging current can reach 100A. It can support up to loads up to 5kw total power or 4HP motor loads, such as air conditioners, electric fans and so on. Its DC output is mainly from PV panels, and its AC in/out is mainly from the utility power, which can also be a gasoline or diesel generator.
The inverter also has a wifi option that allows you to monitor the system remotely from your cell phone or computer.
5KW Hybrid Solar Inverter Overview
During the day the solar panels provide the main power to the load and the excess power is stored in the batteries for use at night. If it is cloudy, in the morning, or at night when the light radiation intensity is not high and the batteries are already dead, the utility or generator will provide power support.
5KW Hybrid Solar Power Inverter Datesheet
| MODEL | SYP 5K-S | CAN BE SET |
| INVERTER OUTPUT | ||
| Rated Outout Power | 5,000W | |
| Max.Peak Power | 10,000VA | |
| Rated Output Voltage | 230Vac (L/N/PE single-phase) | √ |
| Load Capacity of Motors | 4HP | |
| Rated AC Frequency | 50/60Hz | √ |
| Waveform | Pure sine wave | |
| Switch Time | 10ms (typical) | |
| Parallel Capacity | 1-6 units (single/three phase) | |
| BATTERY | ||
| Battery Type | Li-ion / Lead-acid / User-define | √ |
| Rated Battery Voltage | 48Vdc | |
| Voltage Range | 40~60Vdc | √ |
| Max.MPPTCharging Current | 100A | √ |
| Max.Mains/Generator Charging Current | 60A | √ |
| Max.Hybrid Charging Current | 100A | √ |
| PV INPUT | ||
| Num. of MPPT | 1 | |
| Max.PV array power | 5,500W | |
| Max.input current | 22A | |
| Max.Voltage of Open Circuit | 500Vdc | |
| MPPT Voltage Range | 120~450Vdc | |
| MAINS / GENERATOR INPUT | ||
| Input Voltage Range | 90~280Vac | √ |
| Frequency Range | 50/60Hz | |
| Bypass Overload Current | 40A | |
| EFFICIENCY | ||
| MPPT Tracking Efficiency | 99.9% | |
| Max. Battery Inverter Effciency | 92% | |
| GENERAL | ||
| Dimensions | 446.9*350*133mm(1.47*1.15*0.44ft) | |
| Weight | 13kg (28.66lb) | |
| Protection Degree | IP20,indoor only | |
| Operating Temperature Range | -10-55℃ | |
| Noise | ≤60dB | |
| Cooling Method | Forced air cooling with adjustable air speed | |
| Warranty | 18 months | |
| COMMUNICATION | ||
| Embedded Interfaces | RS485 / USB/ Dry contact | √ |
| External Modules(Optional) | Wi-Fi/GPRS | √ |
| CERTIFICATION | ||
| Safety | CE (IEC62109-1/2) | |
| EMC | EN61000 | |
| RoHS | Yes | |
5KW Hybrid Solar Power Inverter Diagram
5KW Hybrid Solar Power Inverter Paralleling Connection
In addition, this 5KW hybrid solar inverter can support up to 6 units in parallel and can be paralleled into a single-phase or three-phase 30kw output.
