5kWh Solar Backup LiFePO4 Battery Is the Best Batteries for Solar Power Storage.
5kw solar battery is another name for 5kWh battery. We all know that the unit of energy of battery is kWh, and the unit of power is kw. If we add a battery with 5kw power discharge for one hour can release its power completely, then we call it 5kWh battery. It is also customarily called a 5kw battery.
JMHPOWER 5kw solar battery is 51.2V 100Ah LiFePO4 battery, the battery case is black, more high-end. The energy utilization efficiency of the battery can go up to more than 98%. The battery is equipped with LED display. It can help you set various parameters of the battery, charging and discharging time, maximum discharging depth, charging voltage, discharging current and so on. It is a safe, efficient and intelligent solar battery.
5kw solar Battery Role
Usually, 5kw solar is paired with a 3kw or 5kw solar system. For example, if a 5kw solar system generates 20kWh of electricity per day, then 5kWh can be stored in the battery for use at night and during power outages. At the same time, when the load is large and the solar generation is unstable, the solar battery can be used to balance and stabilize the household power system.
Suitable family size for 5kw solar battery
If your family size is 1~3 persons or consume 1~4kWh electricity every night on average, then 5kw battery is the best choice for you. It can support 1 or 2 air conditioners, a washing machine, a TV set, several electric lights to work for several hours. Paired with a solar power system, it can save you at least half of your electricity bill.
Features of 5kw solar battery
5kw solar battery is widely used in home energy storage. They have many performance advantages. They are also the best choice for home solar power system.
Good adaptability: The battery is compatible with most brands of solar inverters and chargers on the market and communicates via RS485/CAN protocol. Examples: Growatt, Deye, MUST, SOFAR SOLAR, Victron, Luxpower, Goodwe, etc.
Rational distribution of power: solar battery has an internal battery management system, which can be used with a solar charge controller to set the charging and discharging times of the battery. For example, the battery can only be discharged to the load when the solar power generation efficiency is low, and the utility price is high.
Maintenance-free design: Unlike traditional lead-acid batteries, lithium solar batteries do not require electrolyte reduction over time. So, in the process of use almost do not need any routine maintenance. If the battery fails, it will automatically alarm and send out a fault indication.
Stacking design: the 5kw battery adopts a push-stack design, if you need to get a larger capacity battery, you can just stack multiple batteries and connect them in parallel. It should be noted that, in addition to the parallel connection of the circuit you also need to connect the RS485 communication line of the battery. This way all the battery modules can ensure the same voltage, current and power in the process of using. Up to 64 lithium batteries with a capacity of 5kw solar battery each can be connected in parallel connection, resulting in a total capacity of 320 kWh.
Easy to move: the design with wheels makes it easier and faster to move the battery module, only one person can move the battery easily.
Environmentally friendly: The raw material of the battery does not contain heavy cobalt, lead and other metal elements. This avoids pollution to the environment, and recycling is more convenient.
Smarter: The optional Bluetooth module can be added to the battery, so that it can be interconnected with the battery through the battery phone APP. Check and monitor the status of the battery, the remaining power and other information at any time.
Specifications of 5kWh 48V 100h Lithium Ion Batteries for Sale
| Nominal Voltage: | 48V （16S 51.2V ) |
| Nominal capacity: | 100Ah |
| battery type: | 16S1P Lifepo4 3.2v 100AH |
| weight: | ≤50Kg |
| Dimensions: (LxWxH) | Dimensions of the battery case：620*460*195mm |
| Charging end voltage: | 58.4V16S |
| Connector | M8 bolt screw |
| LED display | LCD display (voltage, capacity, watts, etc.) |
| Low Voltage Protection: | 40V(pack)/2.5V(cell) |
| charging mode: | 0.2C(0.5A) Constant current/constant voltage |
| Communication protocol: | RS485/RS232/CAN |
| Maximum Continuous Discharge Current: | 100A |
| Discharge Over Current Protection: | 100A |
| Over Voltage Protection: | ＞57.6V |
| Operating temperature: | Charge：0~45℃ |
| discharge：-10~55℃ | |
| Storage temperature (60-80% SOC storage): | -10~45℃ |
| Cycle life: | More than 6000 times – 8000 times |
| BMS Protection: | Overcharge, Over-discharge, overcurrent, short circuit |
Best Home Battery Backup, Solar Backup Battery Cost.
| LiFePO4 Battery Capacity | Price |
|---|---|
| 2kWh(24v 100ah) | around $400 |
| 5kWh(48V 100ah) | around $700 |
| 25kWh(48v 500ah) | around $3500 |
| 30kWh(48v 600ah) | around $4000 |
| 100kWh(48v 2000ah) | around $12000 |
We also have other models of batteries available, such as 10kWh, 20kWh, 50kWh, 80 kWh, and 200kWh. We offer home delivery services in regions and countries. Such as Southeast Asian countries, European countries, North American countries, Middle Eastern countries, and Oceanian countries.
