5kW US 120V Single Phase Off Grid Solar Inverter

5kW US version 120V Solar Inverter specification

The JMHPOWER SYP 5K-U is a residential solar storage inverter specially designed for the Americas (USA, Canada, Mexico, Jamaica, El Salvador, Brazil, Chile, etc.). Its output voltage is 120V 60Hz for single phase, or two parallel output 240V 60Hz for split phase, or three parallel output 208V 60Hz for three phase. This basically meets the needs of most of the Americas’ household appliances and small commercial and industrial power supplies. We also have other models that can output 3-phase 440V 60Hz, which are used for large commercial and industrial energy storage inverter systems.

This 5kw US version of the solar storage inverter also has a built-in MPPT PV charger. It can track the maximum power point of the PV panels in time in any environment to maximize the power gained from the solar system. This allows the PV string to be connected directly to the inverter without the need to purchase an additional charge controller.

The inverter utilizes SPWM technology, which provides a pure sine wave output that is suitable for most household appliances such as TVs, washing machines, air conditioners, etc. without damaging them.

5kW US version 120V Solar Inverter Features

1. 4HP motor load capacity

2. Can work without battery: 5kw solar storage inverter can be used with battery, it can work normally without battery, but the system will be more stable if there is battery, especially when the PV power is not very stable and there are high power appliances.

3. 5kw inverter can be used 1~6 in parallel: up to 6 inverters can be connected in parallel to get a total power output of 30kw.

4. Charging mode multiple choices: PV priority, utility priority, PV charging only and hybrid mode.

5. Charge and Discharge Time Setting: You can set the time for the inverter to charge and discharge the battery, so that the battery will supply the consumption of the load when the electricity price is high, saving your electricity bill expenses.

6. Power saving mode: The power saving mode of the inverter will reduce its own loss when there is no load consuming electricity.

7. Supports multiple battery types, maximum 100A charging current

8. BMS interface: 5kw energy storage inverter has BMS interface which can communicate with lithium battery. After the protocol adjustment is consistent, it can realize communication with the battery to ensure the management of the battery by the PV system.

5kw US 120V Single Phase Solar Inverter Datasheet
