100kw solar power systems are mainly for medium sized photovoltaic power generation systems, which are more commonly installed on factory roofs, and it can reduce your business’s electricity bill. The 100kw power output can also meet the needs of many power-using devices. If your business uses a lot of electricity at night, or you are considering making a profit by utilizing the peak and valley tariff difference, then installing a high-capacity energy storage battery is necessary.
Products Categories
Inquiry Now
Buy 100kw Intelligent Distributed Hybrid Energy Storage System Solar Panel and Battery Kit from Chinese Factory.
100kw on grid connected solar pv system for industrial and commercial rooftop projects with lowest cost.
How much electricity does a 100kw solar system produce?
A 100kw solar system can generate between 300kWh and 540kWh of electricity per day. This depends on the different amount of solar radiation in different region. You can refer to the image below to know the peak sunshine hours per day in your area to calculate the amount of power a 100kw system can generate in your area.
For example, if the area is 5kwh per day, then the 100kw can generate 100×5=500kWh per day.
You can also contact us and we will help you calculate the PV power generation according to your city.
100kw Solar System Size
The size of a 100kw solar system is around 450m²/4800ft², this is based on 180 units 550watt solar panel, and the dimensions of the individual 550watt solar panel is 2279x1134mm.
It should be noted that if the solar panels need to be installed at an angle, space needs to be left between the different rows to avoid sunlight being blocked, so that the total area will increase.
100kw Solar System Price
Prices for 100kw systems range from $13000 to $35,000, largely based on the availability of batteries and the size of the battery capacity. The prices of PV mounts, PV panels, and cables vary very little. Feel free to contact me to verify recent discounted prices.
How does a 100kw hybrid solar system work?
The 100kw hybrid solar system is designed to maximize energy efficiency and reliability by seamlessly integrating solar power generation, battery storage, grid interaction, and backup power sources. Through advanced monitoring and remote management capabilities, users can optimize system performance and ensure continuous power supply, making it an ideal solution for meeting diverse energy needs in various scenarios.
1. Solar Power Generation: PV modules capture sunlight and convert it into DC electricity, which is then sent to the combiner box for aggregation.
2. Power Conversion and Distribution: The aggregated DC power is transmitted to the 100KW Hybrid inverter, which converts it into AC electricity suitable for loads and grid connection.
3. Battery Storage: Excess power from the solar system is stored in the batteries for use during periods of low sunlight or high demand.
4. Load Management: The 100kw solar system prioritizes powering connected loads (e.g., air conditioners, EV chargers) using solar-generated electricity, with battery backup available as needed.
5. Grid Interaction: The 100kw solar system is connected to the grid via an ATS, which allows excess power to be fed back into the grid and ensures grid power supply when solar and battery storage are insufficient.
6. Diesel Generator Backup: In case of prolonged power outages or high load demands, a diesel generator (DG) can be integrated to provide additional backup power.
7. Monitoring and Control: The ShineMaster monitoring system, connected via communication cables, collects data on system performance and sends it to a server or app for remote monitoring and control through a router and internet connection.
8. Remote Management: Users can access system data and control settings via an app or web interface, allowing for real-time monitoring and optimization of the system’s performance.
How does a 100kw solar system cope with extreme weather conditions?
- Reinforce the installation structure: ensure that the PV module and support are firm and can withstand strong wind and rainstorm.
- Lightning protection and waterproofing: equipped with lightning protection devices and, an optimized drainage system, to prevent lightning strikes and water accumulation from damaging equipment.
- Energy storage and backup power supply: Utilizing battery energy storage systems and diesel generators to ensure continuous power supply and cope with insufficient sunlight or grid failures.
- Intelligent monitoring and maintenance: Real-time monitoring of system status through intelligent monitoring, regular inspection, and maintenance of equipment, ensuring stable operation of the system in extreme weather conditions.
100kw Solar Power System FAQ
A 100kw solar system can be configured with different types of solar panels, such as 180 pieces 550watt, 220 pieces 450watt, or 330 pieces 300watt solar panels. Among these options, the 550watt solar panels are considered the most cost-effective model based on the size of the container. This is because higher-wattage panels generally require fewer units to achieve the same total power output, which can reduce installation costs and space requirements.
The installation of a 100kw solar system generally does not negatively impact the roof structure, provided that the installation is professionally designed and executed. Modern mounting systems are engineered to distribute the weight of the solar panels evenly across the roof, ensuring structural integrity.
Yes, a 100kw solar system can be combined with other renewable energy sources such as wind or hydropower to create a hybrid system. This integration enhances energy reliability by leveraging the complementary nature of different sources. For example, wind power can offset the variability of solar energy, while hydroelectric power can provide a stable baseline supply.
Yes, a 100kw solar system requires regular maintenance to ensure optimal performance and longevity. Routine tasks include cleaning the panels to remove dirt and debris, inspecting for damage or wear, and monitoring system performance. It is recommended to have a professional service the system at least every two years to check electrical components and connections.
A 100kw solar system is designed to operate efficiently in various environmental conditions. It performs best in sunny climates but can still generate significant power in less ideal conditions with the help of advanced technologies. Modern solar panels are also built to withstand harsh weather, ensuring reliable performance.
